Description
This air filter is made to a 30-3/4 x 27-3/4 x 1″ nominal size for HVAC systems, air handlers, and return grilles that require an exact custom dimension rather than a standard retail size.
A properly fitting filter seals against the housing, so all return air is forced through the media instead of leaking around the frame.
MERV 13 targets the fine particulate fraction that lower MERV ratings allow through — including smoke, bacteria-carrying dust, and combustion byproducts. Airflow resistance is higher than MERV 8 or 11, so systems with borderline static pressure should be evaluated before switching up.
Specifications
- Nominal size: 30-3/4 x 27-3/4 x 1″
- Actual dimensions: 30-3/4 x 27-3/4 x 3/4″
- Efficiency rating: MERV 13
- Quantity: 12 filters per carton
Customers typically order a 30-3/4 x 27-3/4 x 1″ custom filter because their system is older, was built by a regional manufacturer, was retrofitted, or was framed on-site by an installer who didn’t conform to a standard filter dimension. If that describes your situation, you’re in the right place.
Features
- Pleated construction (or fiberglass, depending on MERV tier) designed for balanced capture and airflow
- Cardboard frame with reinforced media for structural stability during handling and installation
- Replace approximately every 90 days in standard installations; shorter intervals in high-dust, smoky, or heavy-use environments
- Orientation arrow printed on the frame to ensure correct airflow direction at install
Same 30-3/4 x 27-3/4 x 1″ size, different efficiency rating
| MERV 1-4Basic dust-stop | MERV 8Standard efficiency | MERV 11Enhanced efficiency |
|
Need 30-3/4 x 27-3/4 x 2″ or another depth? This size is available in other depths we don’t stock online — reach out and our team will quote it for you, typically same business day.
|
