Description
This air filter is made to a 29-5/8 x 23-1/4 x 1″ nominal size for HVAC systems, air handlers, and return grilles that require an exact custom dimension rather than a standard retail size.
Even a quarter-inch of gap around a filter can allow a significant percentage of return air to bypass the media entirely, which is why the exact fit matters as much as the filter’s efficiency rating.
MERV 13 targets the fine particulate fraction that lower MERV ratings allow through — including smoke, bacteria-carrying dust, and combustion byproducts. Airflow resistance is higher than MERV 8 or 11, so systems with borderline static pressure should be evaluated before switching up.
Specifications
- Nominal size: 29-5/8 x 23-1/4 x 1″
- Actual dimensions: 29-5/8 x 23-1/4 x 3/4″
- Efficiency rating: MERV 13
- Quantity: 12 filters per carton
Customers typically order a 29-5/8 x 23-1/4 x 1″ custom filter because their system is older, was built by a regional manufacturer, was retrofitted, or was framed on-site by an installer who didn’t conform to a standard filter dimension. If that describes your situation, you’re in the right place.
Features
- Pleated construction (or fiberglass, depending on MERV tier) designed for balanced capture and airflow
- Replace approximately every 90 days in standard installations; shorter intervals in high-dust, smoky, or heavy-use environments
- Suitable for forced-air furnaces, central AC, heat pumps, and packaged HVAC systems
- Sold as a 12-pack so you have a full year of replacements on hand
Same 29-5/8 x 23-1/4 x 1″ size, different efficiency rating
| MERV 1-4Basic dust-stop | MERV 8Standard efficiency | MERV 11Enhanced efficiency |
|
Need 29-5/8 x 23-1/4 x 2″ or another depth? This size is available in other depths we don’t stock online — reach out and our team will quote it for you, typically same business day.
|
